Carlo Gavazzi DUB01CD48500V Voltage Monitoring Relay, Over or Under Voltage, 2 to 500 V AC/DC

The Carlo Gavazzi DUB01CD48500V is a single phase voltage monitoring relay that detects over voltage or under voltage on AC or DC circuits from 2 to 500 V. It measures true RMS voltage, and the set point, hysteresis and alarm delay are adjusted on front knobs. It is commonly used to watch battery, DC bus and control supply voltages and trip an alarm before equipment is affected.

DAANET is the authorised Australian distributor for Carlo Gavazzi. We supply the DUB01CD48500V locally and provide technical support to help you select the right product for your application.

Typical applications

• Battery and UPS voltage monitoring

• DC bus and solar string monitoring

• Control supply under voltage alarms

• Generator and supply quality monitoring

Key specifications

• Manufacturer: Carlo Gavazzi

• Part number: DUB01CD48500V

• Product range: DUB01

• Function: Over voltage or under voltage monitoring, TRMS AC/DC, selected by DIP switch

• Measuring range: 2 to 500 V AC/DC in 4 ranges (2 to 20 V, 5 to 50 V, 20 to 200 V, 50 to 500 V)

• Settings: Set point 10 to 110%, hysteresis 0 to 30%, alarm delay 0.1 to 30 s

• Latch / inhibit: Selectable via contact input, power on delay 1 or 6 s

• Power supply: 24 to 48 VAC/DC

• Output: 1 x SPDT relay, AC1 8 A at 250 VAC, normally energised or de energised

• Housing: 22.5 mm DIN rail, IP20

• Operating temperature: minus 20 to 60 °C

• Approvals: UL, CSA, CCC

Downloads

• DUB01 datasheet (PDF)

• Installation manual (PDF)

• Carlo Gavazzi product page

Need help choosing a voltage monitoring relay? Contact DAANET to discuss your application.
