About IDEM

IDEM Safety Switches is a globally recognized manufacturer of machine safety products, specialising in innovative solutions that protect both personnel and equipment. Designed and manufactured in the UK, IDEM’s range includes high-performance safety interlocks, emergency stop devices, and non-contact switches engineered for harsh industrial environments.

With a focus on durability, reliability, and compliance, IDEM products are trusted by OEMs and manufacturers across sectors including food and beverage, packaging, automotive, and pharmaceuticals.

As a proud distributor of IDEM in Australia, DAANET supplies both standard and stainless steel safety devices, helping industries meet international safety standards and improve operator safety.

View the latest Catalogue

Non-Contact Safety Switches

MPR Series – RFID coded

SPR Series – Magnetic

Coded Magnetic Series – Slimline

CIP Stainless Steel Series – Harsh environment rated

Tongue Interlock Switches

KLM/KLP Series – Standard

KL3-SS – Guard locking stainless steel

KL4 Series – High retention force

KLTM – Heavy duty tongue switches

Emergency Stop Devices

EGP Series – E-stop with LED indication

ESL Series – Rope-operated e-stop

Safety Control Stations – Panel mount options

Rope Pull Switches

ESL-SS Series – Stainless steel rope switches

GLS Series – Plastic housing

HLM Series – Long distance pull cord

Hinged & Hinge Safety Switches

HS-SS Series – Stainless hinge interlocks

HLM-Hinged Series – Small-form hinge switches

Safety Relays & Accessories

SRL Series – IDEM Safety Relay

LED Indicator Units

M12 Quick Connect Cables

Control Panels & Brackets

Shop IDEM Safety

Featured

Quick View

IDEM Z-Range Standard Duty Rope Pull Safety Switches (GLS-Z)

$723.84

The GLS-Z standard duty safety rope pull switch has been designed to protect medium to long conveyor lengths, where protection is required up to 100m (using 2 switches) or up to 80m (using 1 switch). Body Material: Die-Cast Metal; Painted Yellow Ingress Protection: IP67 Contacts: 2 OSSD + 1 Auxiliary Output Cable Length (1 Switch): 80m Cable Length (2 Switches): 100m

IDEM GLS-SS-Z stainless steel rope pull safety switch

Quick View

IDEM 144300-Z GLS-SS-Z Stainless Rope Pull Safety Switch, 2 OSSD, M12, IP69K

$1,195.69

The IDEM GLS-SS-Z (144300-Z) is a standard duty rope pull safety switch in 316 stainless steel with electronic OSSD outputs. It protects conveyor spans up to 80 m with one switch or 100 m with two. Instead of mechanical contacts it has two PNP OSSD safety outputs and a PNP auxiliary output on an M12 connector, and it is rated IP69K for washdown areas.

DAANET has distributed IDEM Safety Switches in Australia since 2009. We supply IDEM rope pull switches locally and provide technical support to help you lay out conveyor protection that suits your site.

Typical applications

Food and beverage conveyors with washdown
Stainless steel processing lines
Series connected safety systems with safety relays or PLCs
Pharmaceutical and hygienic areas

Key specifications

Manufacturer: IDEM Safety Switches
Part number: 144300-Z
Product range: Z range GLS-SS-Z
Outputs: 2 x OSSD PNP + 1 x PNP auxiliary, 0.2 A
Rope span: 80 m single, 100 m dual
Supply voltage: 24 VDC, minus 15 % to plus 10 %
Connection: 250 mm pigtail with M12 8 pin connector
Housing: 316 stainless steel
Enclosure protection: IP67, IP69K (IP67 at the connector)
Response time: 60 ms max.
Operating temperature: minus 20 to 50 °C
Safety rating: PLe Cat. 4 (ISO 13849-1), SIL3 (IEC 62061)
Approvals: TÜV (internal contact block), cULus

Downloads

Need rope switch protection on a washdown conveyor? Contact DAANET to discuss your application.

Quick View

IDEM Z-Range Mini Duty Rope Pull Safety Switches (GLM-Z)

$726.35

The GLM-Z mini duty safety rope pull switch has been designed to protect short to medium conveyor lengths, where protection is required up to 50m (using 2 switches) or up to 30m (using 1 switch). Body Material: Die-Cast Metal; Painted Yellow Ingress Protection: IP67 Contacts: 2 OSSD + 1 Auxiliary Output Cable Length (1 Switch): 30m Cable Length (2 Switches): 50m

Quick View

IDEM Z-Range Mini Duty Rope Pull Safety Switches (GLM-SS-Z)

$1,126.61

The GLM-SS-Z mini duty safety rope pull switch has been designed to protect short to medium conveyor lengths, where protection is required up to 50m (using 2 switches) or up to 30m (using 1 switch). Body Material: Stainless Steel 316; ideal for exposure to chemical cleaning agents Ingress Protection: IP69K (IP67 at the connector) Contacts: 2 OSSD + 1 Auxiliary Output Cable Length (1 Switch): 30m Cable Length (2 Switches): 50m

Quick View

IDEM Z-Range Heavy Duty Safety Rope Pull Switches with Dual Head (GLHD-Z)

$1,060.74

The GLHD-Z heavy duty safety rope pull switch has been designed to protect long conveyor lengths. The dual head is capable of protecting up to 250m and shorter rope spans up to 200m can be achieved using a single switch. This makes for a cost-effective solution, as it reduces electrical wiring runs and the total number of switches required. Body Material: Die-Cast Metal; Painted Yellow Ingress Protection: IP67 Contacts: 2 OSSD + 1 Auxiliary Output Cable Length (1 Switch): 100m left / 100m right Cable Length (3 Switches): 125m left / 125m right

Quick View

IDEM Z-Range Heavy Duty Safety Rope Pull Switches with Dual Head (GLHD-SS-Z)

$1,567.26

The GLHD-SS-Z heavy duty safety rope pull switch has been designed to protect long conveyor lengths. The dual head is capable of protecting up to 250m and shorter rope spans up to 200m can be achieved using a single switch. This makes for a cost-effective solution, as it reduces electrical wiring runs and the total number of switches required. Body Material: Stainless Steel 316 Ingress Protection: IP69K (IP67 at the connector) Contacts: 2 OSSD + 1 Auxiliary Output Cable Length (1 Switch): 100m left / 100m right Cable Length (3 Switches): 125m left / 125m right

Quick View

IDEM Z-Range Heavy Duty Safety Rope Pull Switches (GLHR-Z)

$766.01

The GLHR-Z heavy duty safety rope pull switch has been designed to protect long conveyor lengths, where protection is required up to 125m (using 2 switches) or up to 100m (using 1 switch). The GLHR-Z can be used on its own or in combination with the GLHD-Z to connect up to 125m rope span from the right side. Body Material: Die-Cast Metal; Painted Yellow Ingress Protection: IP67 Contacts: 2 OSSD + 1 Auxiliary Output Cable Length (1 Switch): 100m Cable Length (2 Switches): 125m

Quick View

IDEM Z-Range Heavy Duty Safety Rope Pull Switches (GLHR-SS-Z)

$1,346.98

The GLHR-SS-Z heavy duty safety rope pull switch has been designed to protect long conveyor lengths, where protection is required up to 125m (using 2 switches) or up to 100m (using 1 switch). The GLHR-SS-Z can be used on its own or in combination with the GLHD-SS-Z to connect up to 125m rope span from the right side. Body Material: Stainless Steel 316 Ingress Protection: IP69K (IP67 at the connector) Contacts: 2 OSSD + 1 Auxiliary Output Cable Length (1 Switch): 100m right Cable Length (2 Switches): 125m right

Quick View

IDEM Z-Range Heavy Duty Safety Rope Pull Switches (GLHL-Z)

$766.01

The GLHL-Z heavy duty safety rope pull switch has been designed to protect long conveyor lengths, where protection is required up to 125m (using 2 switches) or up to 100m (using 1 switch). The GLHL-Z can be used on its own or in combination with the GLHD-Z to connect up to 125m rope span from the left side. Body Material: Die-Cast Metal; Painted Yellow Ingress Protection: IP67 Contacts: 2 OSSD + 1 Auxiliary Output Cable Length (1 Switch): 100m Cable Length (2 Switches): 125m

Quick View

IDEM Z-Range Heavy Duty Safety Rope Pull Switches (GLHL-SS-Z)

$1,346.98

The GLHL-SS-Z heavy duty safety rope pull switch has been designed to protect long conveyor lengths, where protection is required up to 125m (using 2 switches) or up to 100m (using 1 switch). The GLHL-SS-Z can be used on its own or in combination with the GLHD-SS-Z to connect up to 125m rope span from the left side. Body Material: Stainless Steel 316 Ingress Protection: IP69K (IP67 at the connector) Contacts: 2 OSSD + 1 Auxiliary Output Cable Length (1 Switch): 100m left Cable Length (2 Switches): 125m left

Quick View

IDEM Zero Force Button Only (240021)

$458.47

Designed to eliminate hand or wrist stresses associated with frequent repetitive machine operations. They are solid state construction and benefit from LED indication of status. Polyester Construction LED Indication Ergonomic Operation

Quick View

IDEM W-Series Non-Contact Spacer

$25.90

Suitable for use with WPR, WMR, WPC, WMC and WPF Polyester material 9mm Thickness Sold as a pair

Quick View

IDEM Viper Safety Relay with Time Delay (SCR-31-42TD-i)

from $869.10

The SCR-31-42TD-i internal logic uses force guided relays to achieve cross monitoring, ensuring single faults are detected at or before the next demand upon the safety function. Delayed Outputs: 4NC and 2NO (0-30 secs) Standard Outputs: 3NC 1NO Dual Channel Safety Inputs Up to PLe, SIL 3, Category 4

Quick View

IDEM Viper Safety Relay with Added Diagnostics (SCR-73-i)

from $749.77

The SCR-73-i internal logic uses force guided relays to achieve cross monitoring, ensuring single faults are detected at or before the next demand upon the safety function. Outputs 7NC and 3NO contacts Dual Channel Safety Inputs Up to PLe, SIL 3, Category 4 LED Indication for Reset Circuit Status

Quick View

IDEM Viper Safety Relay with Added Diagnostics (SCR-31P-i)

from $356.29

The SCR-31P-i is designed to be compatible with devices offering OSSD/PNP outputs such as safety light curtains, safety mats, safety interlock switches (guard door monitoring) and much more. Outputs 3NC contacts and 1NO contact Dual Channel Safety Inputs Up to PLe, SIL 3, Category 4 LED Indication for Reset Circuit Status

Quick View

IDEM Viper Safety Relay with Added Diagnostics (SCR-21-i)

from $288.24

The SCR-21-i internal logic uses force guided relays to achieve cross monitoring, ensuring single faults are detected at or before the next demand upon the safety function. Outputs 2NC contacts and 1NO contact Dual Channel Safety Inputs Up to PLe, SIL 3, Category 4 LED Indication for Reset Circuit Status

Quick View

IDEM Viper Expansion Unit with Time Delay for SCR-i Safety Relays (SEU-31TD-i)

from $507.32

The SEU-31TD-i is an expansion unit with the added benefit of time delayed contacts. It has been designed to connect to a standard VIPER SCR-i safety relay for extra time delayed output contacts to the end user. Delayed contacts: 3NC 1NO (0-30 seconds) Up to PLd, SIL 2, Category 3

Quick View

IDEM Viper Expansion Unit for SCR-i Safety Relays (SEU-31-i)

from $282.74

The SEU-31-i is an expansion unit for the VIPER SCR-i range and has been designed to connect to a standard SCR-i safety relay to offer extra safety output contacts (3NC + 1NO). Outputs 3NC and 1NO contacts Up to PLe, SIL 3, Category 4
