Carlo Gavazzi DPB02CM48 3 Phase Monitoring Relay, Phase Loss, Sequence and Asymmetry, 380 to 480 VAC

The Carlo Gavazzi DPB02CM48 is a 3 phase monitoring relay that detects phase loss, incorrect phase sequence and voltage asymmetry. The asymmetry limit and alarm delay are set on front dials, and nominal voltage and mains type are selected by DIP switch, so one relay suits both 3 wire and 4 wire systems. It is powered from the monitored phases and also detects regenerated voltage.

DAANET is the authorised Australian distributor for Carlo Gavazzi. We supply the DPB02CM48 locally and provide technical support to help you select the right product for your application.

Typical applications

• Motor protection against unbalanced supplies

• Pumps, fans and compressors

• Switchboards and motor control centres

• Generator and changeover monitoring

Key specifications

• Manufacturer: Carlo Gavazzi

• Part number: DPB02CM48

• Product range: DPB02

• Function: Phase loss, phase sequence and asymmetry monitoring

• Nominal voltage: 380 to 480 VAC L-L (323 to 552 VAC operating range), 3P or 3P+N

• Frequency: 50 to 60 Hz

• Settings: Asymmetry 2 to 22%, alarm delay 0.1 to 30 s, power on delay 1 or 6 s

• Power supply: Self powered from the measured phases

• Output: 1 x SPDT relay, de energised on alarm, AC15 2.5 A at 250 VAC, DC12 5 A at 24 VDC

• Housing: 22.5 mm DIN rail, IP20

• Operating temperature: minus 20 to 60 °C

• Approvals: GB/T14048.5

Downloads

• DPB02 datasheet (PDF)

• Installation manual (PDF)

• Carlo Gavazzi product page

Need help choosing a 3 phase monitoring relay? Contact DAANET to discuss your application.
