Carlo Gavazzi DIB01CD485A Current Monitoring Relay, Over or Under Current, 0.1 to 5 A AC/DC, 24 to 48 V Supply

The Carlo Gavazzi DIB01CD485A is a single phase current monitoring relay that detects over current or under current on AC or DC loads up to 5 A. It measures true RMS current through an internal shunt, and the set point, hysteresis and alarm delay are adjusted on front knobs. Typical uses include detecting a broken belt, a dry running pump or a blocked motor by watching its current draw.

DAANET is the authorised Australian distributor for Carlo Gavazzi. We supply the DIB01CD485A locally and provide technical support to help you select the right product for your application.

Typical applications

• Dry run and blockage detection on pumps

• Broken belt and loss of load detection

• Heater element and lamp failure monitoring

• Overload alarms on small motors and actuators

Key specifications

• Manufacturer: Carlo Gavazzi

• Part number: DIB01CD485A

• Product range: DIB01

• Function: Over current or under current monitoring, TRMS AC/DC, selected by DIP switch

• Measuring range: 0.1 to 5 A AC/DC in 3 ranges (0.1 to 1 A, 0.2 to 2 A, 0.5 to 5 A)

• Settings: Set point 10 to 110%, hysteresis 0 to 30%, alarm delay 0.1 to 30 s

• Latch / inhibit: Latch via contact input, inhibit selectable, power on delay 1 or 6 s

• Power supply: 24 to 48 VAC/DC

• Output: 1 x SPDT relay, AC1 8 A at 250 VAC, DC12 5 A at 24 VDC

• Housing: 22.5 mm DIN rail, IP20

• Operating temperature: minus 20 to 60 °C

• Approvals: UL, CSA, CCC

Downloads

• DIB01 datasheet (PDF)

• Installation manual (PDF)

• Carlo Gavazzi product page

Need help choosing a current monitoring relay? Contact DAANET to discuss your application.
