Carlo Gavazzi DBB51CM2410M True Delay on Release Timer, 60 to 600 s, 24 to 240 VAC / 24 VDC, 17.5 mm

The Carlo Gavazzi DBB51CM2410M is a compact true delay on release timer in a 17.5 mm housing, set between 60 and 600 seconds. The relay pulls in when power is applied, and when power is removed it stays energised for the set time before releasing, with no separate supply needed during timing. It suits longer run on functions such as fan, pump or cooling overrun.

DAANET is the authorised Australian distributor for Carlo Gavazzi. We supply the DBB51CM2410M locally and provide technical support to help you select the right product for your application.

Typical applications

• Fan and extraction run on after shutdown

• Pump and cooling overrun

• Lighting and HVAC off delays

• Space saving timer for crowded DIN rails

Key specifications

• Manufacturer: Carlo Gavazzi

• Part number: DBB51CM2410M

• Product range: DBB51

• Type: True delay on release timer

• Time range: 60 to 600 s

• Power supply: 24 VDC or 24 to 240 VAC

• Output: SPDT relay, AC1 5 A at 250 VAC

• Housing: 17.5 mm DIN rail, 17.5 x 81 x 67.2 mm, IP20

• Operating temperature: minus 20 to 60 °C

• Approvals: UL, CSA

Downloads

• DBB51 datasheet (PDF)

• Installation manual (PDF)

• Carlo Gavazzi product page

Need help choosing the right timer? Contact DAANET to discuss your application.
